A 6 diode constant directional lighting circuit.

This project uses 6 diodes, a section of perfboard (optional), and 4 differently-colored wires. Be sure to use lights rated at 1.5 volts, otherwise they will be much too dim. Note if you downloaded this image before 12/17/95, there was an error, the diodes were installed backwards - this drawing is corrected.
